Slayer Series street carburettors are designed with many of the same innovations and features that are built into all QFT™ race-winning carburettors, including changeable air bleeds and power valve channel restrictions. Its designed with a secondary metering plate with changeable jets, and features all aluminium components for additional weight savings. All Slayer Series carburettors are equipped with universal throttle levers to accommodate Ford A/T kickdown, GM 700 R4 mounting holes, and ability to mount brackets for Chrysler vehicles. Slayer Series are available in 450, 600, and 750 cfm vacuum secondary models.
- Vacuum Secondaries
- Electric Choke
- Single Metering Block
- Secondary Metering Plate
- Cast Aluminium Throttle Body
- Single Sight Glass Windows
- Changeable Air Bleeds
- Adjustable Needles & Seats
- Notched Secondary Floats w/Jet Extensions
SPECS
| Barrels | 4 |
|---|---|
| Billet Color | Diecast-No Billet |
| Booster | Down Leg |
| Brand | Quick Fuel |
| Carburetor Use | Street |
| CFM | 600 |
| Choke | Electric |
| Circuit | 2 |
| Condition | New |
| Emission Code | 3 |
| Finish | Shiny |
| Fuel | Gasoline |
| Fuel System | Carbureted |
| High Speed Air Bleed | 31 |
| Idle Air Bleed Size | 63:78 |
| Marine Use | No |
| Material | Aluminum |
| Model | Slayer Series |
| Primary Main Jet | 66 |
| Primary Power Valve | 65 |
| Primary Pump Nozzle Size | 31 |
| Product Type | Carburetor |
| Secondaries | Vacuum |
| Secondary Main Jet | 74 |
| Supercharged Application | No |
| Throttle Bore | 1-9/16 inch |
| UPC | 849804015311 |
| Part Number | SL-1957E |
